PEMANCAR TV UHF-VHF

Exciter RVR

RVR BLUES30NV||30Watt stereo

All of RVR's Experience in this new ultracompact FM Exciter!Broadcast quality, reliable and at a value price, extremely compact,ideal for STL stations and multi-channel applications via cable.State-of-the-art audio quality for perfect reproduction, fully compliant with FCC,CCIR and all international regulations.Microprocessor-controlled, easy to programme from the menu or via RS232,all main parameters can be read on the LCD display.Integrated high performance stereo coder, L&R inputs, MPX and auxiliariesfor SCA / RDS signals.Output adjustable between 0 and 30 W automatic APC control andFoldback protection, safe operation under all operating conditions.Made using SMD technology, fully solid state, MOSFET RF amplifiers.Ultracompact, non-deformable and light, 1HE rack unit, stainless steel chassis,only kg 6.Maximum operating reliability and stability designed to minimise spare parts.
Product Specifications :
Frequency Range : 87.5 - 108 MHz
Output Power : 30 W
Modulation Type : Direct Carrier Frecuency
AC Power Source : 110 - 230 V
Stereo Separation : 30 Hz - 53 KHz
RF Output Connector : N - Female
Dimensions : 19'' x 1'' x 15.5''
Shipping Weight : 10 Lbs (4.54Kg)
Harga Rp. ==CALL==

RVR TEXT 30LCD||30Watt stereo

Description: - On the front panel, by means a user-friendly graphic interface, all the diagnostic and control parameters are displayed (frequency, output power, measurement, etc.).- Adjustable power output from 0 to 30 W with any VSWR conditions, thanks to FOLD-BACK control of both forward and reflected power. - Power supply multi-voltage from 80 to 260 V directly without selector. - Meets or exceeds all FCC and CCIR requirements. - Low cost with high performance. - Composed of only 4 modules easily replaceable, allowing the realignment of equipment with almost total absence of adjustments. - SMD technology circuits for maximum reliability and minimum encumbrance with optimum signal routing. - Available with 2 SCA/RDS input connectors. - Main parameters available also on terminal board for remote control. - Built-in stereo coder with high performance ( TEX30LCD/S).

Harga Rp. ==CALL==

RVR PJ300LCD||300Watt amplifier

Description: Extra-Compact Quality FM Solid State Amplifier Powerfully and Low-Cost High performance amplifier, compact, reliable and easy maintenance. Broadcast quality at a value price, can be used as drivers for medium power FM stations or as stand-alone applications. Compact, non-deformable and light, 2HE rack unit, stainless steel chassis. Safe operation in any working conditions. Completely microprocessor-controlled easy to program from the menu or via RS232, all main parameters can be read on the LCD display. Possibility to be monitored through all RVR telemetry systems to guarantee simple remote control of the operating parameters. Maximum operating reliability designed to allow an easy maintenance. Universal multi-voltage power supply from 80 to 260 V. Modern technology that complies with all EC, FCC and CCIR standards.
Product Specifications
AC Power Source : 90 V - 250 V Full range
Frequency Range : 87.5 MHz to 108 MHz
Output Power : 300 W
RF Output Connector : N Type
Impedance : 50 Ohm
RF Input Connector : N Type
Input Driver Power : =< 10 W
Dimensions : 3.49'' X 19'' X 14.76''
Shipping Weight : 25 Lbs
Harga Rp. ==CALL==

RVR PJ500LCD||500Watt amplifier

Exceptionally high gain P.A. with relatively low input Automatic gain control providing fixed output power even in case of fluctuating drive power High reliability, easy handling and consistent performance standard achieved among the various units due to total absence of tuning requirements Very high efficiency of P.A., typically capable of more than 500 W, output power with about 8 W of drive input power Composed of two parallel 300 W R.F. power amplifier modules for highest reliability. These modules are coupled through a Wilkinson Splitter and Combiner realized with "Strip-Line Technology" Protection for internal and antenna VSWR, excessive temperature and excessive drive power, with indicator lights, which will put the transmitter driver in stand-by position in the event of failure. It's present a protection that in case of overcurrent on one 300 W P.A. Module reduces the voltage on the drain of the pair of 300 W modules interesting in faulty; then, this protection card check the status of each single R.F. Power Amplifier module's protection fuse High efficiency switching power supply Compact size dimensions with built in power supply Easily replaceable standard components.
Product Specifications
AC Power Source : 100-250 Vac, 50-60 Hz
Frequency Range : 87.5 -108 MHz
Output Power : 500 W typically
RF Output Connector : N-Type
RF Input Connector : N-Type
Dimensions : 5.07'' x 17.52'' x 19.84''
Shipping Weight : 78 Lbs (172 Kg).
Harga Rp. ==CALL==

RVR VJ1000HP||1000Watt Amplifier

Input Broadband, Plate tunes and load motorizad able to cover the entire band 87.5 to 108 MHz. High slope low-pass filter. Output power meter of high exactly (Dir/Ref). Simple and rugger power supply, provided easy access, overload protection fuse failure. Meets or exceeds all FCC and CCIR requirements. Rack 14 units 19" with 4 disposal units. WSWR, grid current and insufficient ventilation protections. Grounded grid power amplifier. No neutralization required. Advanced recycling overload and protection system that provides automatic re-start after about 90 seconds of stand by in case of fault.
Product Specifications
AC Power Source : Single phase: 220-240V
Frequency Range : 87.5 to 108 MHz
Output Power : 900 - 1100 W
RF Input Connector : N Type
Impedance : 50 Ohm
Input Driver Power : 18 W typical, max 25 W
Tube Type : 3CX1500A7 (8877)
Dimensions : 32'' x 26'' x 29''
Shipping Weight : 224 Lbs (101.7 Kg)
Harga Rp. ==CALL==

RVR VJ2000||2000Watt Amplifier

Broadband input Motorized tuning for plate and load,capable of covering the entire 87.5 to 108 MHz band High efficiency low pass filter Higly accurate direct and reflected power metering. Simple and rugged power supply, providing easy access and overload protection. Meets or exceeds all FCC and CCIR requirements 20 standard 19" rack spaces cabinet with 8 available rack spaces. VSWR, grid current,plate current, temperature, safety interlocks and airflow failure protection circuits, No neutralization required. Advanced recycling overload and protection system that provides automatic re-start after about 90 seconds of stand-by in case of fault.This procedure is repeated four times and in case of persisting fault,the cycle re-starts again after 15 minutes, for four more times.If fault still persists, the stop becomes permanent. If instead,during one of the re-starts the fault disappears the counting circuit system is reset after a regular working period of 15 minutes Mono-phase or three-phase version on request.
Product Specifications
AC Power Source : Single phase: 220-240V
Frequency Range : 87.5 to 108 MHz
Output Power : 1800-2200 W
RF Input Connector : N Type
Impedance : 50 Ohm
                                                                Tube : EIMAC 3CX1500 A7 (8877)
                                                                Dimensions : 21.26" x 23.23" x 37.99"
                                                                Harga Rp. ==CALL==

RVR VJ3000||3000Watt Amplifier

Motorized tuning for input, plate and load, capable of covering the entire 87.5 to 108 MHz band. High efficiency low pass filter. High overall efficiency. Remote control. Highly accurate direct and reflected power metering. Timing of electronic start with Time saving. Simple and rugged power supply, providing easy access and overload protection. Meets or exceeds all FCC and CCIR requirements 24 standard 19" rack spaces cabinet. VSWR, grid current, plate current, temperature, safety interlocks, airflow failure protection circuits and unbalanced A.C. line. No neutralization required. Display of the number of interventions. Advanced recycling overload and protection system that provides automatic re-start after about 30 seconds of stand-by in case of fault. This procedure is repeated 9 times and in case of persisting fault the stop becomes permanent until a manual or remote control re-start is applied. If instead during one of the re-starts the fault disappears the counting circuit system is reset after a regular working period of 30 Minutes. Internal memory will display number of interventions and fault cause. Mono-phase or three-phase version on request
Product Specifications :
AC Power Source : Three Phase: 220-240 V
Frequency Range : 87.5 to 108 MHz
Output Power : 3500 W Max
Power Consumption : Approx 6KW
RF Input Connector : N Type
Impedance : 50 Ohm
RF Output Connector : EIA Flange 7/8" (EIA Flange 3+1/8")
Tube : EIMAC 3CX3000A
Dimensions : 22.24" x 48" x 22.24"
Harga Rp. ==CALL===

RVR VJ500||5000Watt Amplifier

otorized tuning for input, plate and load, capable of covering the entire 87.5 to 108 MHz band High efficiency low pass filter. High overall efficiency. Remote control. Highly accurate direct and reflected power metering. Timing of electronic start with Time Saving. Simple and rugged power supply, providing easy access and overload protection. Meets or exceeds all FCC and CCIR requirements. 40 standard 19" rack spaces cabinet. VSWR, grid current, plate current, temperature, safety interlocks, airflow failure protection circuits and unbalanced A.C. line. No neutralization required. Display of the number of interventions. Advanced recycling overload and protection system that provides automatic re-start after about 30 seconds of stand-by in case of fault. This procedure is repeated 9 times and in case of persisting fault the stop becomes permanent until a manual or remote control re-start is applied. If instead during one of the re-starts the fault disappears the counting circuit system is reset after a regular working period of 30 Minutes. Internal memory will display number of interventions and fault cause. Mono-phase or three-phase version on request
Product Specifications :

Output Power : 5500 W Max
Power Consumption : Approx 10KW
Impedance : 50 Ohm
Tube : EIMAC 3CX3000A
Tube Type : Triode
Shipping Weight : 1089 Lbs (490Kg)

Harga Rp. ==CALL==
